Vermont Gage量规套装
材质:工具钢结构
·表面镀铬
·精度2B的塞规用于检测内螺纹尺寸和验证底径实际尺寸是否超过其实体尺寸
·精度2A的塞规用来验证和设置可调螺纹环规
·美标:符合ASME B1.2标准
·公差:class X
·具有可追溯的证书
材质:工具钢结构
·表面镀铬
·精度2B的塞规用于检测内螺纹尺寸和验证底径实际尺寸是否超过其实体尺寸
·精度2A的塞规用来验证和设置可调螺纹环规
·美标:符合ASME B1.2标准
·公差:class X
·具有可追溯的证书

STANDARD CLASS X PIN / PLUG GAGES

Standard Class X Go and NoGo plug gages are used as masters to calibrate equipment or to gage parts directly. Either way, these gages are accurate, cost effective measurement standards for the shop floor and the metrology laboratory.

  • Range: .004” - 1.000”
  • Increments: .0001”
  • Tolerance:
    • + .000040” (up to .8250”)
    •  - .000040” (up to .8250”)
    • + .000060” (.8251 - 1.0000”)
    • - .000060” (.8251 - 1.0000”)
  • Go: Plus Tolerance
  • NoGo: Minus Tolerance
  • Material: Tool Steel 60/65 Rc
  • 2” long
  • 4 Microinch Finish or Better
  • Round within 1/2 the Diameter Tolerance
  • Certificate of Accuracy is included.
  • ISO 17025 Accredited and Non-Accredited Calibration Certificates may be purchased.
   苏州斯文克精密测量设备有限公司专业提供美国Vermont Gage量规,NPT螺纹规、NPSI螺纹规、NPSM螺纹规、ANPT螺纹规、G螺纹规、BSPT螺纹规等。
